| Magnification | 1.7-13.3x |
| Effective objective lens diameter (mm) | 13.6-42 |
| Exit pupil diameter (mm) | 8.1-3.1 |
| Exit pupil distance (mm) (Eye relief) | 95 |
| Field of view (ft/100 yds / m/100 m) | 75.6-9.3 / 25.2-3.1 |
| Field of view (degrees) | 14.4-1.8 |
| Field of view, apparent (degrees) | 24 |
| Dioptric compensation (dpt) | -3 to +2 |
| Light transmission (%) | 93 |
| Twilight factor acc. to ISO 14132-1 | 4.8-23.6 |
| Impact point corr. per click (in/100 yds / mm/100 m) | 0.36 / 10 |
| Max. elevation / windage adjustment range (in/100 yds / m/100 m) | 54 / 1.5 |
| Parallax correction (yds / m) | 55-∞ / 50-∞ |
| Objective filter thread | M 44x0.75 |
| Length ( mm) | 336 |
| Weight ( g) | 620 |
| Central tube diameter (mm) | 30 |
| Functional temperature | -20 °C / +55 °C |
| Storage temperature | --30 °C / +70 °C |
| Submersion tightness | 4 m water depth (inert gas filling) |
| Brightness levels | Twilight: 0 - 32 / Day: 33 - 64 |
| Operating time (h) | Twilight factor at medium brightness: 1,400; daylight factor at medium brightness: 180 |
